Case study: URL shortener

A URL shortener turns a long link into a short code, such as sho.rt/x7Kp2Qa, and sends anyone who opens that code to the long link. It is the standard interview warm-up. The product is small, but the design still covers estimates, unique IDs, a read-heavy cache and an async analytics path.

The key idea is asymmetry. Redirects happen about 100 times as often as links are created. So the redirect path gets a strict latency budget, and everything else can be slower.

Requirements

Functional

• Create a short link for a long URL, with an optional custom alias and expiry.
• Redirect a short code to its long URL.
• Count clicks per link.

Non-functional

• Redirects: p99 under about 50 ms in one region, with very high availability.
• Codes must be unique.
• Links live for years, 5 or more by default.
• Creates can take hundreds of milliseconds.

The numbers

Assume 100 million new URLs per month and a 100:1 read-to-write ratio.

Seconds per month ≈ 2.6 million      (30 days × 86,400 s)
Writes (avg):   100M / 2.6M          ≈ 40 creates/s
Writes (peak):  40 × 3               ≈ 120 creates/s
Reads (avg):    40 × 100             ≈ 4,000 redirects/s
Reads (peak):   4,000 × 3            ≈ 12,000 redirects/s
Links (5 years): 100M × 12 × 5       = 6 billion
Storage:         6B × ~500 B         ≈ 3 TB

Creates at about 120 per second need no special write pipeline. Redirects at about 12,000 per second need horizontal scale and a cache.

Design at a glance

The create path leases or encodes a code, inserts the row and returns the short URL. The redirect path checks the cache, falls back to the database on a miss, emits a click event and returns the redirect. The click event is sent after the redirect decision, so analytics never blocks the user.

Concepts in this topic

API and data model

POST /api/v1/links
Idempotency-Key: …
{ "url": "https://example.com/a/very/long/path", "alias": null, "expiresAt": null }
→ 201 { "code": "x7Kp2Qa", "shortUrl": "https://sho.rt/x7Kp2Qa" }

GET /x7Kp2Qa
→ 302 Location: https://example.com/a/very/long/path

Every redirect is a primary-key lookup on code. Keep the links table as the mapping source of truth, and keep click totals somewhere else.

CREATE TABLE links (
  code       varchar(10) PRIMARY KEY,
  long_url   text        NOT NULL,
  owner_id   bigint,
  created_at timestamptz NOT NULL DEFAULT now(),
  expires_at timestamptz,
  is_active  boolean     NOT NULL DEFAULT true
);

Key-value stores partitioned by hash(code) fit this access pattern well. Codes from a counter or hash look random enough that hash sharding spreads the load.

Caching

Use cache-aside on code → {long_url, expires_at, is_active}, with a TTL of hours plus jitter. On create or disable, delete the key instead of overwriting it. A viral code can cause a stampede when its key expires, so guard it with single-flight or early refresh (see cache stampede).

Failure modes

Common mistakes

• Counting clicks on the links row. Every redirect then becomes a write to your busiest table.
• Choosing 301 for a product that sells analytics. Browsers may stop calling you at all.
• Tying redirect success to analytics. If the analytics queue is slow, redirects should still work.

Key takeaways

• Redirects dominate, so design the read path first: cache, scale out, optionally use a CDN.
• Seven base62 characters cover billions of links with room to spare.
• Use 302 or 307 when you need click counts or expiry.
• Send click events asynchronously and never let them block a redirect.
